We have made it!

Irfan

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;
using Emgu.CV;
using Emgu.CV.Structure;
using Emgu.CV.Cvb;
using Emgu.CV.CvEnum;
namespace Hakaton
{
 public partial class Form1 : Form
 {
 private VideoCapture videoCapture;
 private bool detectFire;
 private bool frameSkip = true;
 private double redThreshold = 220;
 private double whiteThreshold = 220;
 private int frameInterval = 1000 / 30;
 private Timer fpsTimer;
 public Form1()
 {
 InitializeComponent();
 Init();
 }
 private void Init()
 {
 picPreview.SizeMode = PictureBoxSizeMode.StretchImage;
 picRedFilter.SizeMode = PictureBoxSizeMode.StretchImage;
 picFinal.SizeMode = PictureBoxSizeMode.StretchImage;
 trbSeek.Enabled = false;
 }
 private void OpenVideo(string filename)
 {
 videoCapture = new VideoCapture(filename);
 int frameCount = (int) videoCapture.GetCaptureProperty(CapProp.FrameCount);
 trbSeek.Minimum = 0;
 trbSeek.Maximum = frameCount;
 trbSeek.Value = 0;
 trbSeek.Enabled = true;
 fpsTimer = new Timer();
 fpsTimer.Interval = frameInterval;
 fpsTimer.Tick += ProcessFrame;
 fpsTimer.Start();
 }
 private void OpenCamera()
 {
 videoCapture = new VideoCapture();
 trbSeek.Enabled = false;
 frameSkip = false;
 Application.Idle += ProcessFrame;
 }
 private void ProcessFrame(object sender, EventArgs e)
 {
 DateTime methodStart = DateTime.Now;
 Image<Bgr, Byte> redFiltered = null;
 Image<Bgr, Byte> ycbcrFiltered = null;
 Image<Gray, Byte> blobImage = null;
 Image<Bgr, Byte> rawFrame = videoCapture.QueryFrame().ToImage<Bgr, Byte>();
 rawFrame = rawFrame.Resize(320, 240, Emgu.CV.CvEnum.Inter.Cubic);
 rawFrame._EqualizeHist();
 if (detectFire)
 {
 redFiltered = redTreshhold(rawFrame);
 ycbcrFiltered = yCbCrThreshold(redFiltered);
 blobImage = binaryTreshold(ycbcrFiltered);
 CvBlobs blobs = new CvBlobs();
 CvBlobDetector blobDetector = new CvBlobDetector();
 uint blobCount = blobDetector.Detect(blobImage, blobs);
 int minArea = (int)(rawFrame.Width * rawFrame.Height * 0.002);
 foreach (KeyValuePair<uint, CvBlob> blobPair in blobs)
 {
 if(blobPair.Value.Area > minArea)
 {
 Rectangle rect = blobPair.Value.BoundingBox;
 rawFrame.Draw(rect, new Bgr(0, 255, 0), 5);
 }
 }
 }
 picPreview.Image = rawFrame.Bitmap;
 if(detectFire)
 {
 picRedFilter.Image = redFiltered.Bitmap;
 picFinal.Image = blobImage.Bitmap;
 }
 else
 {
 picRedFilter.Image = null;
 picFinal.Image = null;
 }
 if(frameSkip)
 {
 int timePassed = (DateTime.Now - methodStart).Milliseconds;
 int framesToSkip = timePassed / frameInterval;
 for (int i = 0; i < framesToSkip; i++)
 videoCapture.QueryFrame();
 }
 int currentFrame = (int) videoCapture.GetCaptureProperty(CapProp.PosFrames);
 int frameCount = (int) videoCapture.GetCaptureProperty(CapProp.FrameCount);
 if(currentFrame != -1 && frameCount != -1)
 {
 trbSeek.Value = currentFrame;
 if (currentFrame == frameCount)
 CloseVideo();
 }
 }
 private void CloseVideo()
 {
 fpsTimer.Stop();
 picPreview.Image = null;
 picRedFilter.Image = null;
 picFinal.Image = null;
 }
 Image<Gray, Byte> binaryTreshold(Image<Bgr, Byte> originalImage)
 {
 Image<Gray, Byte> newImage = new Image<Gray, byte>(originalImage.Width, originalImage.Height);
 Bgr black = new Bgr(0, 0, 0);
 for (int y = 0; y < originalImage.Height; y++)
 {
 for (int x = 0; x < originalImage.Width; x++)
 {
 if (originalImage[y, x].Equals(black))
 newImage[y, x] = new Gray(0);
 else
 newImage[y, x] = new Gray(255);
 }
 }
 return newImage;
 }
 Image<Bgr, Byte> redTreshhold(Image<Bgr, Byte> originalImage)
 {
 Image<Bgr, Byte> newImage = new Image<Bgr, byte>(originalImage.Width, originalImage.Height);
 for (int y = 0; y < originalImage.Height; y++)
 {
 for (int x = 0; x < originalImage.Width; x++)
 {
 double r = originalImage[y, x].Red;
 double g = originalImage[y, x].Green;
 double b = originalImage[y, x].Blue;
 bool isFire = false;
 if (r > g && r > b)
 if (r > redThreshold)
 isFire = true;
 if (r > whiteThreshold && g > whiteThreshold && b > whiteThreshold)
 isFire = true;
 if (isFire)
 newImage[y, x] = originalImage[y, x];
 else
 newImage[y, x] = new Bgr(0, 0, 0);
 }
 }
 return newImage;
 }
 Image<Bgr, Byte> yCbCrThreshold(Image<Bgr, Byte> originalImage)
 {
 Image<Bgr, Byte> newImage = new Image<Bgr, byte>(originalImage.Width, originalImage.Height);
 for (int Y = 0; Y < originalImage.Height; Y++)
 {
 for (int X = 0; X < originalImage.Width; X++)
 {
 double rRaw = originalImage[Y, X].Red;
 double gRaw = originalImage[Y, X].Green;
 double bRaw = originalImage[Y, X].Blue;
 double r = rRaw / 255;
 double g = gRaw / 255;
 double b = bRaw / 255;
 double y = 0.299 * r + 0.587 * g + 0.114 * b;
 double cB = -0.168736 * r + -0.331264 * g + 0.500 * b;
 double cR = 0.500 * r + -0.418688 * g + -0.081312 * b;
 bool isFire = false;
 if(y >= cR && cR >= cB)
 {
 double crcb = cR - cB;
 double ycb = y - cB;
 if (!((crcb >= -0.1 && ycb >= -0.1 && ycb <= 0.3) || (crcb >= 0 && crcb <= 0.4 && ycb >= 0 && ycb <= 0.8)))
 isFire = true;
 }
 if (isFire)
 isFire = !(cR - cB > -0.1 && y - cB > -0.1 && y - cB <= 0.6);
 if (isFire)
 newImage[Y, X] = originalImage[Y, X];
 else
 newImage[Y, X] = new Bgr(0, 0, 0);
 }
 }
 return newImage;
 }
 private void chkDetect_CheckedChanged(object sender, EventArgs e)
 {
 detectFire = chkDetect.Checked;
 }
 private void trbSeek_Scroll(object sender, EventArgs e)
 {
 int frameIndex = trbSeek.Value;
 videoCapture.SetCaptureProperty(CapProp.PosFrames, frameIndex);
 }
 private void chkFrameSkip_CheckedChanged(object sender, EventArgs e)
 {
 frameSkip = chkFrameSkip.Checked;
 }
 private void btnCamera_Click(object sender, EventArgs e)
 {
 OpenCamera();
 }
 private void btnVideo_Click(object sender, EventArgs e)
 {
 OpenFileDialog dialog = new OpenFileDialog();
 DialogResult result = dialog.ShowDialog();
 if(result.Equals(DialogResult.OK))
 if(dialog.FileName != null)
 OpenVideo(dialog.FileName);
 }
 }
}

view raw cs hosted with ❤ by GitHub

Tarik Omercehajic

Our journey has started!

Tarik Omercehajic

SpaceApps is a NASA incubator innovation program.

	using System;
	using System.Collections.Generic;
	using System.ComponentModel;
	using System.Data;
	using System.Drawing;
	using System.Linq;
	using System.Text;
	using System.Threading.Tasks;
	using System.Windows.Forms;
	using Emgu.CV;
	using Emgu.CV.Structure;
	using Emgu.CV.Cvb;
	using Emgu.CV.CvEnum;

	namespace Hakaton
	{
	public partial class Form1 : Form
	{
	private VideoCapture videoCapture;
	private bool detectFire;
	private bool frameSkip = true;

	private double redThreshold = 220;
	private double whiteThreshold = 220;
	private int frameInterval = 1000 / 30;

	private Timer fpsTimer;

	public Form1()
	{
	InitializeComponent();
	Init();
	}

	private void Init()
	{
	picPreview.SizeMode = PictureBoxSizeMode.StretchImage;
	picRedFilter.SizeMode = PictureBoxSizeMode.StretchImage;
	picFinal.SizeMode = PictureBoxSizeMode.StretchImage;

	trbSeek.Enabled = false;
	}

	private void OpenVideo(string filename)
	{
	videoCapture = new VideoCapture(filename);

	int frameCount = (int) videoCapture.GetCaptureProperty(CapProp.FrameCount);
	trbSeek.Minimum = 0;
	trbSeek.Maximum = frameCount;
	trbSeek.Value = 0;
	trbSeek.Enabled = true;

	fpsTimer = new Timer();
	fpsTimer.Interval = frameInterval;
	fpsTimer.Tick += ProcessFrame;
	fpsTimer.Start();
	}

	private void OpenCamera()
	{
	videoCapture = new VideoCapture();
	trbSeek.Enabled = false;
	frameSkip = false;

	Application.Idle += ProcessFrame;
	}

	private void ProcessFrame(object sender, EventArgs e)
	{
	DateTime methodStart = DateTime.Now;

	Image<Bgr, Byte> redFiltered = null;
	Image<Bgr, Byte> ycbcrFiltered = null;
	Image<Gray, Byte> blobImage = null;

	Image<Bgr, Byte> rawFrame = videoCapture.QueryFrame().ToImage<Bgr, Byte>();
	rawFrame = rawFrame.Resize(320, 240, Emgu.CV.CvEnum.Inter.Cubic);
	rawFrame._EqualizeHist();

	if (detectFire)
	{
	redFiltered = redTreshhold(rawFrame);
	ycbcrFiltered = yCbCrThreshold(redFiltered);
	blobImage = binaryTreshold(ycbcrFiltered);

	CvBlobs blobs = new CvBlobs();
	CvBlobDetector blobDetector = new CvBlobDetector();
	uint blobCount = blobDetector.Detect(blobImage, blobs);

	int minArea = (int)(rawFrame.Width * rawFrame.Height * 0.002);

	foreach (KeyValuePair<uint, CvBlob> blobPair in blobs)
	{
	if(blobPair.Value.Area > minArea)
	{
	Rectangle rect = blobPair.Value.BoundingBox;
	rawFrame.Draw(rect, new Bgr(0, 255, 0), 5);
	}
	}
	}

	picPreview.Image = rawFrame.Bitmap;
	if(detectFire)
	{
	picRedFilter.Image = redFiltered.Bitmap;
	picFinal.Image = blobImage.Bitmap;
	}
	else
	{
	picRedFilter.Image = null;
	picFinal.Image = null;
	}

	if(frameSkip)
	{
	int timePassed = (DateTime.Now - methodStart).Milliseconds;
	int framesToSkip = timePassed / frameInterval;
	for (int i = 0; i < framesToSkip; i++)
	videoCapture.QueryFrame();

	}

	int currentFrame = (int) videoCapture.GetCaptureProperty(CapProp.PosFrames);
	int frameCount = (int) videoCapture.GetCaptureProperty(CapProp.FrameCount);
	if(currentFrame != -1 && frameCount != -1)
	{
	trbSeek.Value = currentFrame;
	if (currentFrame == frameCount)
	CloseVideo();
	}
	}

	private void CloseVideo()
	{
	fpsTimer.Stop();
	picPreview.Image = null;
	picRedFilter.Image = null;
	picFinal.Image = null;
	}

	Image<Gray, Byte> binaryTreshold(Image<Bgr, Byte> originalImage)
	{
	Image<Gray, Byte> newImage = new Image<Gray, byte>(originalImage.Width, originalImage.Height);

	Bgr black = new Bgr(0, 0, 0);
	for (int y = 0; y < originalImage.Height; y++)
	{
	for (int x = 0; x < originalImage.Width; x++)
	{
	if (originalImage[y, x].Equals(black))
	newImage[y, x] = new Gray(0);
	else
	newImage[y, x] = new Gray(255);
	}
	}

	return newImage;
	}

	Image<Bgr, Byte> redTreshhold(Image<Bgr, Byte> originalImage)
	{
	Image<Bgr, Byte> newImage = new Image<Bgr, byte>(originalImage.Width, originalImage.Height);

	for (int y = 0; y < originalImage.Height; y++)
	{
	for (int x = 0; x < originalImage.Width; x++)
	{
	double r = originalImage[y, x].Red;
	double g = originalImage[y, x].Green;
	double b = originalImage[y, x].Blue;

	bool isFire = false;

	if (r > g && r > b)
	if (r > redThreshold)
	isFire = true;

	if (r > whiteThreshold && g > whiteThreshold && b > whiteThreshold)
	isFire = true;

	if (isFire)
	newImage[y, x] = originalImage[y, x];
	else
	newImage[y, x] = new Bgr(0, 0, 0);
	}
	}

	return newImage;
	}

	Image<Bgr, Byte> yCbCrThreshold(Image<Bgr, Byte> originalImage)
	{
	Image<Bgr, Byte> newImage = new Image<Bgr, byte>(originalImage.Width, originalImage.Height);

	for (int Y = 0; Y < originalImage.Height; Y++)
	{
	for (int X = 0; X < originalImage.Width; X++)
	{
	double rRaw = originalImage[Y, X].Red;
	double gRaw = originalImage[Y, X].Green;
	double bRaw = originalImage[Y, X].Blue;

	double r = rRaw / 255;
	double g = gRaw / 255;
	double b = bRaw / 255;

	double y = 0.299 * r + 0.587 * g + 0.114 * b;
	double cB = -0.168736 * r + -0.331264 * g + 0.500 * b;
	double cR = 0.500 * r + -0.418688 * g + -0.081312 * b;

	bool isFire = false;

	if(y >= cR && cR >= cB)
	{
	double crcb = cR - cB;
	double ycb = y - cB;
	if (!((crcb >= -0.1 && ycb >= -0.1 && ycb <= 0.3) \|\| (crcb >= 0 && crcb <= 0.4 && ycb >= 0 && ycb <= 0.8)))
	isFire = true;
	}

	if (isFire)
	isFire = !(cR - cB > -0.1 && y - cB > -0.1 && y - cB <= 0.6);

	if (isFire)
	newImage[Y, X] = originalImage[Y, X];
	else
	newImage[Y, X] = new Bgr(0, 0, 0);
	}
	}

	return newImage;
	}

	private void chkDetect_CheckedChanged(object sender, EventArgs e)
	{
	detectFire = chkDetect.Checked;
	}

	private void trbSeek_Scroll(object sender, EventArgs e)
	{
	int frameIndex = trbSeek.Value;
	videoCapture.SetCaptureProperty(CapProp.PosFrames, frameIndex);
	}

	private void chkFrameSkip_CheckedChanged(object sender, EventArgs e)
	{
	frameSkip = chkFrameSkip.Checked;
	}

	private void btnCamera_Click(object sender, EventArgs e)
	{
	OpenCamera();
	}

	private void btnVideo_Click(object sender, EventArgs e)
	{
	OpenFileDialog dialog = new OpenFileDialog();
	DialogResult result = dialog.ShowDialog();
	if(result.Equals(DialogResult.OK))
	if(dialog.FileName != null)
	OpenVideo(dialog.FileName);
	}
	}
	}
